Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine

Introducing our factory's innovative Modified Packaging Sealing Machine for efficient food packing. From fresh poultry to frozen beefsteak, we've got you covered.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Parameters
  • Detailed Photos
  • Company Profile
  • After Sales Service
  • Related Packing Product
Overview

Basic Info.

Model NO.
KIS-4
Forming Function
Seal, Map
Driven Type
Pneumatic
Material Type
Grain
Packaging
Cartons
Packaging Material
Film
Tray Sealing
Sandwich, Fast Food Box, Tofu Box, Lunch Box
Date Printing
Color Ribbon
Fresh Poultry
Fresh Poultry Modified Packaging Machine
Map Packaging
Vacuum, Gas
Packing Machine
Map Packing Machine
Transport Package
Wooden Box
Specification
C
Trademark
Chunlai
Origin
Wenzhou, China
HS Code
8422303090
Production Capacity
50 Sets One Month

Product Description



Product Description

KIS-4 Tray Vacuum Gas Flushing Packing Sealing Machine is vertical type vacuum and gas-flush pneumatic tray sealing system, vacuums the tray completely before it inserts gas. The machine is built in stainless steel for use in hygienic environments. The system is tooled up to your specific tray size and neatly trims the film around the perimeter of the tray, the wasted film is then taken up onto the motorized film feeding system. This machine requires a compressed air connection.



The food trays are manually placed in the tray carrier drawer. As a safety precaution, the operation is initiated by the two handed release system.

The tray carrier moves automatically into the machine and the machine head comes down and seals around the tray carrier.

The large capacity vacuum pump efficiently evacuates the chamber and the gas-flush is carried out.

The sealing head then moves down, completing the perimeter seal around the tray as well as a neat perimeter cut.

The tray carrier drawer then automatically moves back out to the operator and the trays may be removed.

While removal and reloading of the trays takes place, the film is automatically fed to the new position. The new position is determined by either time, blank film counting (to calculate the film length of tray for saving the film cost) or by photocell sensor mark (for printed film).

Product Parameters


production capacity
200-400 trays/hour
power
1.2 Kw
temperature
0-300 .C
voltage
220V 50Hz
dimension
900mmx800mmx1850mm
weight:
150kg

Detailed Photos

Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
KIS-4 vertical type tray sealing machine


Main Function:
machine slide mould automatically
put cup on mould manually
machine slide mould automatically
pneumatic sealing
machine slide mould automatically
take cup outside mould manually


optional customized:
sealing only
vacuum
gas flushing
vacuum + gas packing sealing
vacuum skin packing
Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
KIS-1 semi automatic tray sealer
Main Function:pull mould manually
put cup/tray on mould manually
push mould manually
pneumatic sealing
pull mould manually
take cup/tray outside mould manually
KIS-1 automatic tray sealer
Main Function:machine slide mould automatically
put tray on mould manually
machine slide mould automatically
pneumatic sealing
machine slide mould automatically
take tray outside mould manually

optional customized:
sealing only
gas flushing
KIS-1 automatic cup sealer
Main Function:machine slide mould automatically
put cup on mould manually
machine slide mould automatically
pneumatic sealing
machine slide mould automatically
take cup outside mould manually

optional customized:
sealing only
gas flushing
Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
KIS-1 cup sealer
Main Function:machine slide mould automatically
put cup on mould manually
put foil lid manually
machine slide mould automatically
pneumatic sealing
machine slide mould automatically
take cup outside mould manually

optional customized:
put foil lid automatically

KIS-1 can sealer
put can manually
pneumatic sealing
take can outside manually
AS-4 vertical type tray sealer
Main Function:machine slide mould automatically
put cup on mould manually
machine slide mould automatically
pneumatic sealing
machine slide mould automatically
take cup outside mould manually

optional customized:
sealing only
vacuum
gas flushing
vacuum + gas packing sealing
vacuum skin packing

Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
AS-1 manual tray sealer
Main Function:pull mould manually
put tray on mould manually
push mould manually
manually sealing
pull mould manually
taketray outside mould manually
AS-2 pneumatic tray sealer
Main Function: pull mould manually
put tray on mould manually
push mould manually
pneumatic sealing
pull mould manually
take tray outside mould manually
film straight cutting
AS-2 cup sealer
Main Function:machine slide mould automatically
put cup on mould manually
machine slide mould automatically
pneumatic sealing
machine slide mould automatically
take cup outside mould manually

optional customized:
sealing only
gas flushing



Company Profile

Chunlai is a reputed manufacturer for different kinds of automatic filling & sealing packaging machines. For more than 10 years, Chunlai supplys packaging machines that fully meet customer's requirements.

No matter your product is solid, liquid, paste, powder or granule, Chunlai has machine meet your packaging requirement. Chunlai offer packaging machines for rice packing, seafood packing, beverage packing, dairy packing, soybean product packing, snack food packing, fast food packing, daily product packing, cosmetic product packing, etc...
Chunlai provides a comprehensive experienced technical service. This ensures you the high quality production, secure sealing finish, ease operation and minimum maintenance.
Each machine is carefully inspected and tested by our highly experienced staff before shipment.

Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine
Noodles Sauce Grape Strawberry Blueberry Chicken Toe Frozen Food Packing Beefsteak Jackfruit Mushroom Fresh Poultry Modified Packaging Sealing Machine

After Sales Service

Online after sales service

Related Packing Product



Filling for liquid, paste, granule, powder and so on.
Sealing for cup, bottle, bowl, tray, can, jar, bucket etc..
Yogurt/Milk/Coffee Creamer/Cheese/Butter Water/Juice/Oil Ice Cream/Calippo
Jam/Ketchup/Chili Sauce/Caviar Honey/Chocolate/Candy Coffee/Tea
Cereal/Corn Flakes/Nuts/Oats/Popcorn Jelly/Pudding/Syrup/Caramel Tofu/Bean Curd
Instant Noodles/Pasta/Ready Meal Porridge/Rice Coffee/Tea
Frozen Food/Meat/Seafood/Fish/Shrimp Vegetable/Fruit Edible Oil/Motor Oil
Potato Chips Canister/Paper Facial Tissue Wet Wipe Canister Dehumidifier Box
Lotion/Liquid Soap/Cosmetic/Shampoo Laundry Detergent/Liquid Soap Toilet Detergent/Bleach
Hummus/Tahina/Salad/Mayonnaise/Dip Seasoning Pets Food
